| AMBIENT | 40°C |
| BEARING | Sleeve |
| BLOWER TYPE | Furnace |
| BRAND | Century |
| C DIMENSION | 9.83 IN |
| CATALOG NUM | B6520 |
| CE | No |
| CONNECTION DRAWING NO | 617836 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 2 A |
| FRAME | 42Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/4 1/5 1/6 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 16 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | B6520 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | B6520 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.7 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 4.7 IN |
| SHAFT TYPE | Flat |
| SKU | B6520 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | B6520A |
| SUPPLIER | Regal Beloit Epc |
| THRU BOLTS EXTENSION | Yes |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674012739 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 8 IN |
