| AMBIENT | 50°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 13.05 IN |
| CATALOG NUM | B2977 |
| CONNECTION DRAWING NO | D0000026-001.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | DRIP PROOF |
| FL AMPS | SF 8.7-1.9 A |
| FRAME | Y56J |
| FRAME LENGTH | 8 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 11 IN |
| HORSE POWER | 1-1/2-1/5 HP |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 16 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | B2977 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2/4 |
| NUMBER OF SPEEDS | 2-2-VT |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | B2977 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise |
| RPM | 3450/1725(2-2-VT) |
| SERVICE FACTOR | 1.3 |
| SHAFT | 0.625 IN X 2.57 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 2.57 IN |
| SHAFT TYPE | 7/16 Threaded |
| SKU | B2977 |
| SPEED | 3450/1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674069627 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 34 LB |
| WIDTH | 9.5 IN |
