| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.8 IN |
| CATALOG NUMBER | ARB2034L6 |
| CONNECTION DRAWING NO | 621804-001A |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 4.9/2.3-2.5 A |
| FRAME | 48 |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.31 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 11.88 IN |
| MANUFACTURE MODEL NUMBER | ARB2034L6 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 62 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/3 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/3,1725,115/208-230,48Y,TEAO,SPLIT PH |
| PRODUCT SKU | ARB2034L6 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.655 IN X 1.56 IN |
| SHAFT DIAMETER (IN IN.) | 0.655 IN |
| SHAFT EXTENSION | 1.56 IN |
| SHAFT TYPE | Flat |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/208-230 V |
| WIDTH | 5.81 IN |
