| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.97 IN |
| CATALOG NUM | ARB2034L5 |
| CATALOG NUM STATIC | Arb2034L5 |
| CE | No |
| CONNECTION DRAWING NO | 619785-014C |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 7.3/3.8-3.8 A |
| FRAME | 56Z |
| FRAME LENGTH | 5.19 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56Z |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| HORSE POWER | 1/3 HP |
| HORSE POWER STATIC | 3-Jan |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 14 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | ARB2034L5 |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | ARB2034L5 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.625 IN X 1.62 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.62 IN |
| SHAFT TYPE | Keyed |
| SKU | ARB2034L5 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674011640 |
| VOLTAGE | 115/208-230 V |
| VOLTAGE STATIC | 115/208-230 |
| WEIGHT STATIC | 24 LB |
| WIDTH | 9 IN |
