| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.97 IN |
| CATALOG NUMBER | ARB2034L4 |
| CONNECTION DRAWING NO | 619785-052C |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 5.6/2.8 A |
| FRAME | 56Z |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 14 IN |
| MANUFACTURE MODEL NUMBER | ARB2034L4 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/3 HP |
| PRODUCT NAME | 1/3,1800,115/208-230,56Z,TEAO,SPLIT |
| PRODUCT SKU | ARB2034L4 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.625 IN X 1.62 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.62 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/208-230 V |
| WIDTH | 9 IN |
