| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.97 IN |
| CATALOG NUMBER | ARB2034L3 |
| CONNECTION DRAWING NO | 620005-013A |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 5.6/3.2 A |
| FRAME | 56Z |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 14 IN |
| MANUFACTURE MODEL NUMBER | ARB2034L3 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/3-1/9 HP |
| PRODUCT NAME | 1/3,1800(2),115,56Z,TEAO,SPLIT |
| PRODUCT SKU | ARB2034L3 |
| ROTATION | Reversible |
| RPM | 1725/1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.62 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.62 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725/1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | No |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 9 IN |
