| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.97 IN |
| CATALOG NUM | ARB2034L1 |
| CE | No |
| CONNECTION DRAWING NO | 618191-001A |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 5.5/4 A |
| FRAME | 56Z |
| FRAME LENGTH | 6.19 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| HORSE POWER | 1/3-1/9 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 14 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | ARB2034L1 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | ARB2034L1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725/1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.62 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.62 IN |
| SHAFT TYPE | Keyed |
| SKU | ARB2034L1 |
| SPEED | 1725/1140 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | No |
| UOM | Each |
| UPC NUMBER | 786674050823 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 29 LB |
| WIDTH | 9 IN |
