| AMBIENT | 40°C |
| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 21.5 IN |
| CATALOG NUM | 7RAB4010 |
| CE | No |
| CONNECTION DRAWING NO | 630450 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.6 A |
| FRAME | 42Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 1/10 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 22.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 7RAB4010 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 7RAB4010 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1050(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 8.8 X .5 X 8.8 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 8.8X.5X8.8 IN |
| SHAFT TYPE | Flat |
| SKU | 7RAB4010 |
| SPEED | 1050 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674010988 |
| VOLTAGE | 277 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 6.81 IN |
