| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 10.36 IN |
| CATALOG NUMBER | 7FD6000A |
| CONNECTION DRAWING NO | 614131-265 |
| DUTY | Air Over |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.8 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 13.78 IN |
| MANUFACTURE MODEL NUMBER | 7FD6000A |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Ring/Extended Studs |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/2-1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2-1/6,1200,277,48Y,PSC,MASTERFIT-W/SPL CAP |
| PRODUCT SKU | 7FD6000A |
| ROTATION | Reversible |
| RPM | 1075(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 277 V |
| WIDTH | 6.41 IN |
