| BEARING | Sleeve |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 12.49 IN |
| CATALOG NUMBER | 7FD1024S |
| CONNECTION DRAWING NO | 614131-242 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 1.35 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | A |
| LEAD TIME | 18 |
| LENGTH | 15.18 IN |
| MANUFACTURE MODEL NUMBER | 7FD1024S |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/4,1625,277,48,OPEN,PSC,AUTO,SLV |
| PRODUCT SKU | 7FD1024S |
| ROTATION | Reversible |
| RPM | 1625(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 8 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 8 IN |
| SHAFT TYPE | Flat |
| SPEED | 1625 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 277 V |
| WIDTH | 7.31 IN |
